Testing & Inspection

Westley Group has two finish machine shops, both offering a complete fitting and assembly service for all types of product.

Machining everything that we cast is core to the Group’s strategy. This vertically integrated manufacturing platform provides our customers with a complete solution, as well as consistency and security of supply. We have an all-encompassing range of destructive and non-destructive tests providing quality assurance in line with most stringent supply parameters. All of our quality procedures are approved to minimum ISO 9001 standards, with approvals for numerous institutions, organisations and third party assurance bodies such as FM Approvals.

Our technical and laboratory teams include fully trained and qualified metallurgists responsible for material analysis of our own alloying processes and certified melt stock. This ensures that all of our material meets not only the chemical requirements of our customers’ orders, but also provides traceability to the furnace batch itself. All melts are given their own unique melt number and records are kept by our quality department.

The complexity of the products we supply can only be supported by our industry leading manufacturing platform. We are able to produce sand castings, centrifugal castings, die castings, shell castings and bought-in forgings / bar / stampings.

All components are measured and validated by a combination of mobile and fixed CMM measuring equipment, digital micrometres, digital shadow graph and surface finish testing machinery. Substantial investment has been made in this critical process to ensure we are equipped with the most up to date measuring equipment in ideal environments. Component testing is often based on non-destructive examination by utilising dye penetrant or radiographic procedures. A great deal of our product is supplied to applications requiring PED approval, therefore a large proportion of our testing involves hydrostatic testing from a few bar, up to very high pressure. Witness testing during all or part of the process is easily accommodated.

Assembly operations are managed within stand-alone production cells and supported by our electronic MRP systems. Our electronic MRP system have undergone bespoke modification to enable us to launch unique bills of materials at different levels of the manufacturing process.

Spunalloys and Meighs & Westleys Inspection

Digital Calipers / Micrometres:

  • Manufacturer: Mitutoyo/Moore and Wright
  • Capacity: Up to 1000mm
  • Measurements: Bores, grooves, wall thickness and recesses are checked with ease

Manual Calipers / Micrometres:

  • Manufacturer: Mitutoyo/Moore and Wright
  • Capacity: Up to 1400mm
  • Measurements: Bores, grooves, wall thickness and recesses are checked with ease

Manual CMM:

  • Manufacturer: Mitutoyo
  • Capacity: X1500 x Y600 x Z800mm
  • Measurements: angles, diameters, centres, cones, spheres and intersection points, concentricity, squareness with dimensional printouts
  • Accuracy: 0.008mm





FARO Arm:

  • Manufacturer: FARO
  • Capacity: 2.7m (9) – Seven axes
  • Measurements: Portable measurement arm. Cartesian, polar coordinates – angles, intersection points
  • Accuracy: Single point 0.029, volumetric +/-0.04

Various Thread Plug Gauges:

  • NPT,API,BSP,BSPT,BSPF,UNC,UNF,METRIC

Digital Co-ordinate Height Gauge:

  • Manufacturer: Mitutoyo
  • Capacity: upto1000MM
  • Measurements: Diameters – point-to-point dimensions depths using different types of styles
  • Accuracy: +/- 0.010mm

Ultrasonic Thickness Gauge:

  • Manufacturer: Sauter
  • Capacity: 0.75-80mm
  • Measurements: Wall thickness

Francis Birketts and Walter Frank Inspection

CMM:

  • Manufacturer: ITP
  • Capacity: 300 x 300 x 400mm – three axes
  • Measurements: Cartesian / Polar co-ordinates – angles, diameters, centres, cones, spheres and intersection points with dimensional printouts
  • Accuracy: +/- 0.015mm

Digital Co-ordinate Height Gauge:

  • Manufacturer: Trimos
  • Capacity: 2400mm – two axes
  • Measurements: Diameters – point-to-point dimensions depths using different types of styles
  • Accuracy: +/- 0.010mm

FARO Arm:

  • Manufacturer: FARO
  • Capacity: 1200mm – three axes
  • Measurements: Portable measurement arm. Cartesian, polar coordinates – angles, intersection points
  • Accuracy: ±0.00015mm

Digital Shadow Graph:

  • Manufacturer: Batty R14 – digital
  • Capacity: 150mm dia.
  • Measurements: Non-contact measurement. Geometric function for skew alignment – circles, lines, angles, radius and chamfer measurement.

Bower Digital Bore Micrometres:

  • Manufacturer: Mitutoyo
  • Capacity: 20mm – 150mm
  • Measurements: Electronic measuring scales provide direct readout of mainly bores – checks any ovality and roundness
  • Accuracy: ± 0.0005mm

Digital Tele Surf:

  • Manufacturer: Mitutoyo
  • Measurements: Surface roughness measurements – In Ra, Rq and Rz. Prints measurements with customer, part number, batch number for traceability.

Digital Calipers / Micrometres:

  • Manufacturer: Mitutoyo
  • Capacity: Up to 800mm
  • Measurements: Bores, grooves, wall thickness and recesses are checked with ease

Haas Machining Centre Automatic Probing:

  • Machining centres with wireless intuitive probing system (WIPS) which enables precision measurements of components while still in the machine.
